Performance
Processor
Processor Family
AMD Ryzen™ 5 / 7 7000 Series Processor
Processor**
Processor Name Cores Threads Base Frequency Max Frequency Cache Processor Graphics
AMD Ryzen™ 5 7535HS 6 12 3.3GHz 4.55GHz 3MB L2 / 16MB L3 AMD Radeon™ 660M
AMD Ryzen™ 7 7735HS 8 16 3.2GHz 4.75GHz 4MB L2 / 16MB L3 AMD Radeon™ 680M
Operating System
Operating System**
Windows® 11 Pro
Windows® 11 Home
Windows® 11 Home Single Language
No preload operating system
Graphics
Graphics**
Graphics Type Memory TGP Key Features
AMD Radeon™ 660M Integrated Shared Share CPU TDP DirectX® 12
AMD Radeon™ 680M Integrated Shared Share CPU TDP DirectX® 12
Monitor Support
Monitor Support
Supports up to 4 independent displays (native display and 3 external monitors via HDMI® and USB-C®)
• HDMI® supports up to 4K@60Hz
• USB-C® supports up to 4K@60Hz
Chipset
Chipset
AMD SoC (System on Chip) platform
Memory
Max Memory
16GB soldered memory, not upgradable
32GB soldered memory, not upgradable
Memory Slots
Memory soldered to systemboard, no slots, dual-channel
Memory Type[1]
LPDDR5x-6400
Notes:
1. Installed memory is LPDDR5x, but runs as LPDDR5 due to platform limitation.
Storage
Storage Support[2]
Up to two drives, 2x M.2 SSD
• M.2 2242 SSD up to 1TB
Storage Slot
Two M.2 2280 PCIe® 4.0 x4 slots
Storage Type
Disk Type Interface Offering
M.2 2242 SSD PCIe® NVMe®, PCIe® 4.0 x4 512GB / 1TB
Notes:
1. The storage capacity supported is based on the test results with current Lenovo® storage offerings.
2. The system supports dual SSD via two M.2 slots, but Lenovo® offers only one SSD configuration with a second slot for user self-expansion.
Removable Storage
Card Reader
microSD card reader
Multi-Media
Audio Chip
High Definition (HD) Audio
Speakers
Stereo speakers, 2W x2, optimized with Dolby Audio™
Microphone
Dual-microphone array
Camera
FHD 1080p + IR, with privacy shutter, fixed focus, with ToF sensor
Battery
Battery**
54.7Wh Rechargeable Li-ion Battery, supports Rapid Charge Boost (get 2 hours of runtime with a 15-minute charge)
70Wh Rechargeable Li-ion Battery, supports Rapid Charge Boost (get 2 hours of runtime with a 15-minute charge)
Max Battery Life[1]
Local video (1080p) playback@150nits: 21.4 hr
Notes:
1. All battery life claims are approximate maximum and based on results using the MobileMark® 2014, MobileMark® 2018, MobileMark® 25, MobileMark® 30, JEITA 2.0, JEITA 3.0, continuous 1080p video playback (with 150nits brightness and default volume level) or Google Power Load Test (PLT) battery-life benchmark tests. Actual battery life will vary depending on many factors such as product configuration and usage, software use, wireless functionality, power management settings, and screen brightness. The maximum capacity of the battery will decrease with time and use.
Power Adapter
Power Adapter**[1]
65W USB-C® (3-pin) AC adapter, supports PD 3.0, 100-240V, 50-60Hz
65W USB-C® slim (wall-mount) AC adapter, supports PD 3.0, 100-240V, 50-60Hz
Notes:
1. AC adapter offerings depend on the country.
Design
Display
Display**
Size Resolution Touch Type Brightness Surface Aspect Ratio Contrast Ratio Color Gamut Refresh Rate Viewing Angle (L/R/U/D) Key Features
15.1″ WQXGA (2560×1600) None OLED 500nits Glossy 16:10 100,000:1 100% DCI-P3 165Hz 89° / 89° / 89° / 89° TÜV Low Blue Light (Hardware), DisplayHDR™ True Black 600
15.3″ WUXGA (1920×1200) None IPS[1] 300nits Anti-glare 16:10 1200:1 100% sRGB 60Hz 89° / 89° / 89° / 89° TÜV Low Blue Light (Software)
Touchscreen
Non-touch
Notes:
1. IPS (in-plane switching) technology may refer to IPS, PLS, ADS, AHVA, AAS.
Input Device
Pen
No support
Keyboard
6-row, multimedia Fn keys, Copilot key
Keyboard Backlight
LED backlight
Non-backlight
Touchpad
Buttonless glass surface multi-touch touchpad, supports Precision TouchPad (PTP), 80 x 135 mm (3.15 x 5.31 inches)
Mechanical
Dimensions (WxDxH)[1] Click here to see dimension diagram
339.33 x 236 x 15.6 mm (13.36 x 9.29 x 0.61 inches)
Weight[2]
Around 1.49 kg (3.28 lbs)
Case Color**
Cloud grey
Seafoam green
Surface Treatment
Aluminium stamping (anodized with sandblasting)
Case Material
Aluminium (top), aluminium (bottom)
Notes:
1. The system dimensions may vary depending on configurations.
2. The system weight is approximate and based on results in Lenovo® lab, which varies depending on the source of component, variance of the distribution of each component, and manufacturing process. It may not be the exact weight for each specific model.
Connectivity
Network
WLAN + Bluetooth[1]
Wi-Fi® 6, 802.11ax 2×2 Wi-Fi® + Bluetooth® 5.3, M.2 card[2]
WWAN
No support
Ethernet
No onboard Ethernet
Notes:
1. Bluetooth® may operate at a lower version than hardware design depending on the factors such as operating system, driver, etc.
2. Wi-Fi 6 operation is subject to the regulation rules in each country.
Ports[1] Click here to see ports position
Standard Ports
1x USB-A (USB 5Gbps / USB 3.2 Gen 1)
1x USB-A (USB 5Gbps / USB 3.2 Gen 1), Always On
2x USB-C® (USB 10Gbps / USB 3.2 Gen 2), with USB PD 3.0 and DisplayPort™ 1.4
1x HDMI® 2.1, up to 4K/60Hz
1x Headphone / microphone combo jack (3.5mm)
1x microSD card reader
Notes:
1. The transfer speed of the ports will vary and, depending on many factors, such as the processing speed of the host device, file attributes and other factors related to system configuration and your operating environment, will be slower than theoretical speed.
Docking
Docking
Various docking solutions supported via USB-C®.
For more compatible docking solutions, please visit Docking for IdeaPad® Slim 5 15ARP10
Security & Privacy
Security
Security Chip
Microsoft® Pluton TPM 2.0 Enabled
Fingerprint Reader
No fingerprint reader
BIOS Security
Administrator password
Master hard disk password
Power-on password
User hard disk password
User password
Self-healing BIOS
More BIOS security features, please visit BIOS Simulator[1]
Other Security
Camera privacy shutter
IR camera for Windows® Hello (facial recognition)
Notes:
1. The BIOS simulator is just for reference. Default settings and some options may vary depending on the hardware, operating system and BIOS version.
Service
Warranty
Base Warranty**
1-year courier or carry-in service
1-year courier or carry-in with 2-year system board service (Korea only)
2-year (1-yr battery) courier or carry-in service
3-year (1-yr battery) courier or carry-in service
Accessories
Bundled Accessories
Bundled Accessories**[1]
Lenovo® WL310 Bluetooth® Silent Mouse
Lenovo® WL310 Bluetooth® Silent Mouse without battery
None
Notes:
1. For more compatible accessory solutions, please visit Accessories for IdeaPad® Slim 5 15ARP10.
Operating Requirements
Operating Environment
Temperature[1]
At altitudes up to 2438 m (8,000 ft)
– Operating: 5°C to 35°C (41°F to 95°F)
– Storage: 5°C to 43°C (41°F to 109°F)
At altitudes above 2438 m (8,000 ft)
– Maximum temperature when operating under the unpressurized condition: 31.3°C (88°F)
Relative Humidity
Operating: 8% to 95% at wet-bulb temperature 23°C (73°F)
Storage and transportation: 5% to 95% at wet-bulb temperature 27°C (81°F)
Altitude
Maximum altitude (without pressurization): 3048 m (10,000 ft)
Notes:
1. When you charge the battery, its temperature must be no lower than 10°C (50°F).
Certifications
Green Certifications[1]
Green Certifications[2]
ENERGY STAR® 8.0
EPEAT™ Gold Registered[3]
ErP Lot 6/26
RoHS compliant
Notes:
1. The items listed under the “Green Certifications” section may not only refer to certification but also registration or self-declaration. For ESG & regulatory compliance documents, please visit https://compliance.lenovo.com.
2. EPEAT™ registration and ENERGY STAR® certification are optional and only available on the models with preloaded OS. Please visit epeat.net and energystar.gov for more information.
3. EPEAT is registered where applicable, please visit epeat.net for registration status by country.
Other Certifications
Mil-Spec Test
MIL-STD-810H military test passed (21 test items)
Other Certifications
(Optional) TÜV Rheinland® Low Blue Light (Hardware Solution)
TÜV Rheinland® Low Blue Light (Software Solution)
