Image Sensor
1/2.7″ Progressive Scan CMOS

Shutter Speed
Self-adaptive shutter

Lens

4 mm at f/2.0. Field of View: 46° (vertical), 89° (horizontal), 104° (diagonal)

6 mm at f/2.0. Field of View: 28° (vertical), 52° (horizontal), 60° (diagonal)

PT Angle
Pan: 350°, Tilt: 80°

Minimum Illumination
0.5 Lux (at F1.6, AGC on), 0 Lux with IR (Data provided by EZVIZ Labs)

Lens Mount
M12

Day/Night Function
IR-cut filter with auto switch

Digital Noise Reduction (DNR)
3D Digital Noise Reduction

Wide Dynamic Range (WDR)
Digital Wide Dynamic Range

IR Night Vision Range
30 m (98 ft)

Video and Audio
Max. Resolution
1920 × 1080

Frame Rate
Max: 30 fps; self-adaptive during network transmission

Video Compression
H.265 / H.264

H.265 Type
Main Profile

Video Bitrate
Full HD; High Definition; Standard. Adaptive bitrate.

Audio Bitrate
Self-adaptive

Max Bitrate
2 Mbps

Network
Wi-Fi Standard
IEEE 802.11b, 802.11g, and 802.11n

Frequency Range
2.4 GHz–2.4835 GHz

Channel Bandwidth
Supports 20 MHz

Transmission Rate

11b: 11 Mbps

11g: 54 Mbps

11n: 72 Mbps

Wi-Fi Pairing
Access point pairing

Protocol
EZVIZ Cloud proprietary protocol

Interface Protocol
EZVIZ Cloud proprietary protocol

Wired Network
RJ45 × 1 (10M/100M adaptive Ethernet port)
